Graphic COG
Graphic COG
shared：
| Part No. | Display Format | LCD Mode | LCD Size(mm) | V.A(mm) | A.A(mm) | Backlight | Controller&Driver IC | Type | Datasheet |
| ADG6464A1 | 6464 | FSTN | 30*36/32 | 30*28 | 23.66*23.66 | WHITE | ST7567 | COG+FPC |  |
| ADG9648A1 | 9648 | FSTN | 40*30 | 34.6*20.5 | 32.39*17.99 | BLUE | ST7549T-G2 | COG+FPC | |
| ADG9680A1 | 9680 | DFSTN | 28.1*22.6 | 20.6*20.6 | 17.5*17.2 | WHITE | ST7571_V1 | COG+FPC | |
| ADG11265A1 | 11265 | FSTN | 40*42 | 35*30 | 33.02*26.955 | WHITE | ST7567 | COG+FPC | |
| ADG12832A3 | 128*32 | FSTN | 74*35 | 63.9*15.6 | 60.9*13.42 | WHITE | ST7567 | COG+FPC | |
| ADG12864A4 | 12864 | STN | 54*42/35 | 50*31.5 | 47.96*28.76 | NO | SPLC501C | COG+FPC | |
| ADG12864A5 | 12864 | FSTN | 79*51.2/45.2 | 76*42.2 | 72*38 | NO | ST7565P | COG+FPC | |
| ADG12864A7 | 12864 | FSTN | 48*36/27 | 44*24 | 39.01*20.45 | NO | ST7565R | COG+FPC | |
| ADG12864A8 | 12864 | FSTN | 67*35.6/31 | 64*28 | 59*23 | NO | ST7565R | COG+FPC | |
| ADG12864A10 | 12864 | FSTN | 69*46/41 | 66.5*38 | 60.775*32.935 | NO | ST7565R | COG+FPC | |
| ADG12864A12 | 12864 | FSTN | 40.8*34.8/28.65 | 37.7*25.1 | 34.53*21.7 | NO | ST7565R | COG+FPC | |
| ADG12864A13 | 12864 | STN | 57.6*42.1/35.1 | 54.6*32 | 49.89*27.49 | WHITE | ST7565P | COG+FPC | |
| ADG12864A14 | 12864 | STN | 57.2*42.5/35.5 | 54.2*32.5 | 47.965*26.525 | NO | ST7565R | COG+FPC | |
| ADG12864A15 | 12864 | STN | 75.2*53.15 | 66*33.2 | 55.01*27.49 | WHITE | ST7565R | COG+FPC | |
| ADG12864A16 | 12864 | FSTN | 63*42.5/36 | 59*32 | 55.01*27.49 | WHITE | ST7565P | COG+FPC | |
| ADG12864A17 | 12864 | FSTN | 35.2*29.5/22.5 | 32.2*19.5 | 27.41*16.29 | NO | SSD1815BZ | COG+FPC | |
| ADG12864A19 | 12864 | FSTN | 39.3*25.8/21.02 | 36.32*18.62 | 34.92*17.45 | NO | UC1701 | COG+FPC | |
